CASANOVA - fogal refrigeration

The Casanova model has been designed to be placed behind the delicatessen counter in supermarkets. Options such as the meat bar or the refrigerated under storage (to keep dairy and sliced products) have been conceived in order to give the retailer the maximum operating comfort. In addition to this, as a space-saving solution, Casanova can be supplied without the lower storage and be placed on existing work tops.

DIMENSIONS
nominal lengths / real lenghts (mm) for special lengths, please get in touch with our sales dpt. 100 ( 960 ) 120 ( 1250 ) 150 ( 1510 ) 180 ( 1856 ) 240 ( 2436 ) 300 ( 2956 ) 360 ( 3648 )
plug-in √	remote √
depth mm
standard: 790 slim: 635
plug-in √	remote √
height mm
2095
plug-in √	remote √
1580 SPI (without lower part)
plug-in	remote √
front height mm
780
plug-in √	remote √

STRUCTURE
steel and wood water-repellent chipboard framework
plug-in √	remote √
solid ends

plug-in √	remote √
panoramic ends

plug-in √	remote √
on demand	on demand
self and slow closing glass sliding doors (low-emission thermal glass closing system designed by Fogal Refrigeration)

plug-in √	remote √
on demand	on demand
hinged glass doors (low-emission thermal glass closing system designed by Fogal Refrigeration)

plug-in √	remote √
on demand	on demand
lower ambient part with sliding little doors. Note: only for remote versions, available without evaporation drip tray

plug-in	remote √
lower part equipped with removable panel and aeration grills. Note: standard feature on remote versions with evaporation drip tray

plug-in √	remote √
SPI (without lower part)
plug-in	remote √
	on demand
Night blind – motorised version available

plug-in √	remote √
on demand	on demand
Manual shutter white/ grey/ stainless steel effect

plug-in √	remote √
on demand	on demand
Motorised shutter white/grey/stainless steel effect

plug-in √	remote √
on demand	on demand
Rear loading doors (available with full doors or glass doors and white or aluminium frame)

plug-in √	remote √
on demand	on demand
adjustablefeet

plug-in √	remote √
castors for an easier movement of the cabinet

plug-in √	remote √
on demand	on demand
Base shelf + 3 rows of adjustable complete shelves with brackets and ticket strips
plug-in √	remote √

TECNOLOGY
remote
on demand
plug – in
monophase ermetic compressor 230V-50Hz
electronic fans
plug-in √	remote √
fan assisted refrigeration system
plug-in √	remote √
fan assisted condensing system
plug-in √	remote
electronically controlled refrigeration system
plug-in √	remote √
thermal expansion valve
plug-in √	remote √
stainless steel tray for the automatic collection and evaporation of the waste water by means of hot gas
plug-in √	remote
stainless steel tray for the automatic evaporation of the waste water by way of a self adjusting PTC sensor
plug-in √	remote √
	on demand
low noise level (≤ 40 dBA) _ cabinets with front doors
plug-in √	remote √
multiplexible
plug-in √	remote √
top LED light
plug-in √	remote √
climatic class 3 (ambient temperature up to 25°C, max relative humidity 60%)
plug-in √	remote √
product temperature class
3M1 _ -1 +5°C (range reg. 0/+2°C)
plug-in √	remote √
3M2 _ -1 /+7°C (range reg. +3/+5°C)
plug-in √	remote √
Refrigerant gas R290
plug-in √	remote
Refrigerant gases: Co2 R513a R448a R407a R407c R134a R452a R449a R407f glicole
plug-in	remote √
	on demand

AVAILABLE CLADDINGS
with aluminium trims and ABS inner profiles black and dark grey color on demand

plug-in √	remote √
internal and external visible parts epoxy powder coated – white color
plug-in √	remote √
polished or satined stainless steel internal and external parts Note: on stainless steel cabinets, some components are made of galvanized or powder coated plate
plug-in √	remote √
on demand	on demand
internal and external RAL color coating

plug-in √	remote √
on demand	on demand
wide range of laminated external cladding

plug-in √	remote √
on demand	on demand
wide range of OPTIONS available
plug-in √	remote √
on demand	on demand
